ARC 250 Inverter Welding Rectifiers( An ISO 9001:2008 Certified Company )

 ARC 250 Inverter Welding Rectifiers
ac250
Salient Features
  • Light Weight
  • Low Power Consumption
  • Excellent reliability with high performance, suitable for outdoor onsite use.
  • Immunity from AC inpur fluctuation of ±15 % with built-in overload protection.
  • In-built hot start facility ensures easy arc striking.
  • Ideal for Tig welding with suitable accessories.
  • Remote control facility.


  • Special Features
  • Ideal for project site jobs, Light weight and small dimension makes easy for Transportation and Loading Unloading
  • Class "F" insulation
  • One End Heating Machines

    TECHNICAL SPECIFICATION.     ARC 250
    Input
    Supply Voltage 440V ±15% 3Phs 50/60Hz AC
    Rated Input 15A
    Output
    Output Range 20-250 Amps. DC
    Maximum Current 250 Amps.
    Duty Cycle @ 60% 30V/250A
    Duty Cycle @ 100% 28V/200A
    Open Circuit Voltage 58V
    Protection Class IP21
    Insulation Class F
    Cooling Type Fan Cooled
    Efficiency 0.85
    Dimention(MM) 480*204*303
    Net Weight 18 Kg
    Arcing Way 4.2 MM
